FAA INFORMATION EFFECTIVE 05 OCTOBER 2023

FAA Identifier:

JFX

Lat/Long:

33-54-07.2000N 087-18-49.8000W
33-54.120000N 087-18.830000W
33.9020000,-87.3138333
(estimated)

Elevation:

482.6 ft. / 147.1 m (surveyed)

Variation:

01W (1995)

From city:

5 miles NW of JASPER, AL

Time zone:

UTC -5 (UTC -6 during Standard Time)

Zip code:

35503

Airport use:

Open to the public

Control tower:

no

ARTCC:

ATLANTA CENTER

FSS:

ANNISTON FLIGHT SERVICE STATION

NOTAMs facility:

ANB (NOTAM-D service available)

Attendance:

MON - SAT 0700-2000

Wind indicator:

lighted

Segmented circle:

yes

Lights:

ACTVT REIL RWY 9 & 27; VASI RWY 9 & 27; MIRL RWY 9/27- CTAF.

Beacon:

white-green (lighted land airport)
Operates sunset to sunrise.

CTAF/UNICOM:

122.7

WX AWOS-3PT:

119.225 (205-295-5539)

BIRMINGHAM APPROACH:

127.675 [0600-0000]

BIRMINGHAM DEPARTURE:

127.675 [0600-0000]

VOR radial/distance

VOR name

Freq

Var

VUZr302/24.9

VULCAN VORTAC

114.40

02E

OKWr355/40.0

BROOKWOOD VORTAC

111.00

00E

Fuel available:

100LL JET-A JET-A1
100LL:FUEL AVBL 24/7 WITH CC.

Parking:

tiedowns

Airframe service:

MAJOR
NO OUTSIDE WORK EXCP EMERGS.

Powerplant service:

MAJOR
NO OUTSIDE WORK EXCP EMERGS.

Bottled oxygen:

NONE

Bulk oxygen:

NONE

Runway 9/27

Dimensions:

5004 x 100 ft. / 1525 x 30 m

Surface:

asphalt, in fair condition

Weight bearing capacity:

Runway edge lights:

medium intensity

RUNWAY 9

RUNWAY 27

Latitude:

33-54.132552N

33-54.105750N

Longitude:

087-19.324725W

087-18.335835W

Elevation:

482.3 ft.

473.8 ft.

Traffic pattern:

left

left

Runway heading:

093 magnetic, 092 true

273 magnetic, 272 true

Displaced threshold:

no

190 ft.

Declared distances:

TORA:5001 TODA:5001 ASDA:4800 LDA:4800

TORA:5001 TODA:5001 ASDA:5001 LDA:4800

Markings:

Non precision, in fair condition

precision, in fair condition

Visual slope indicator:

4-box VASI on left (3.00 degrees glide path)

4-box VASI on left (3.00 degrees glide path)

Runway end identifier lights:

yes

yes

Touchdown point:

yes, no lights

yes, no lights

Instrument approach:

ILS/DME

Obstructions:

24 ft. trees, 570 ft. from runway, 113 ft. left of centerline, 15:1 slope to clear

13 ft. trees, 716 ft. from runway, 127 ft. right of centerline, 39:1 slope to clear

Owner:

WALKER COUNTY COMMISSION
1801 3RD AVE. S., SUITE 113
JASPER, AL 35501
Phone 205-384-7230

STEVE MILLER, CHAIRMAN.

Glen Peek, County, ENGR,

Manager:

KEITH DUNCAN
198 BIDDLE DRIVE
JASPER, AL 35503
Phone 205-388-1294

-

DEER ON & INVOF RWYS.

-

GCO AVBL ON FREQ 121.725 THRU BIRMINGHAM (BHM) CLEARANCE DELIVERY.

-

FOR CD IF UNA VIA GCO CTC BIRMINGHAM APCH AT 205-769-3890.


IAPs - Instrument Approach Procedures

ILS OR LOC RWY 27

download (270KB)

RNAV (GPS) RWY 09

download (252KB)

RNAV (GPS) RWY 27

download (264KB)

VOR/DME-A

download (189KB)

NOTE: Special Alternate Minimums apply

download (154KB)

NOTE: Special Take-Off Minimums/Departure Procedures apply

download (488KB)
